Blue Roller Shutter Door Roll Forming Machine Continuous PU Sandwich Panel Production Line

Name: Blue Roller Shutter Door Roll Forming Machine Continuous PU Sandwich Panel Production Line
Brand: Feixiang
Price: 1 USD

Buy cheap Blue Roller Shutter Door Roll Forming Machine Continuous PU Sandwich Panel Production Line product

Brand Name : Feixiang

Model Number : FX85

Certification : CE BV ISO

Place of Origin : China

MOQ : 1set

Price : Please check with the supplier

Payment Terms : L/C, T/T, D/P, D/A, Western Union, MoneyGram

Supply Ability : 30 sets per week

Delivery Time : 15 days

Packaging Details : Nude packing,but we can also packing according the customer requirements

Machine name : sheet metal roll forming machines

size : 6000*800*900mm

Weight : 6.3tons

Control : PLC computer with different language

Speed : 15m/min

Material : GI,PPGI.AL

Contact Now

Blue Roller Shutter Door Roll Forming Machine Continuous PU Sandwich Panel Production Line

1. Description

This Door System PU Foam Rolling Shutter Door Machine is fully automatic . PU foam shutter door can stop the cold air into the house by door and keep your home warmer than normal door in winter , that's why it is so popular in so many cold place in winter. Its raw material is steel strip . Usually the forming speed is 8-15 meter /min , if the clients require a fast speed , we can also produce it for you .

2. Main Material used

Material: Color steel ,galvanized steel or Aluminum
Feeding width:120mm
Material thickness:0.3-0.8mm
Yield strength:235-450mpa

3. Machine composition

Name	SET	Use TO
3T Manual decoiler	1 set	Loading the coil
Main forming machine and cutter	1 set	forming the shape.Cutting the length as request.
PLC control system	1set	1.Language as request 2.Text and touch screen for chose 3.Brand PLC:Panasonic /Delta /Mitsubish
Oil pump	1 set	Make coolling as request
Product stand	1 set	Stand finishing product
Remark	All equipment can order as customer’s request

4. Main parameters

Model number	Blue Roller Shutter Door Roll Forming Machine Continuous PU Sandwich Panel Production Line
Rolled material	0.3-0.8mm thickness, aluminum sheet, galvanized sheet, colored steel sheet and various steel plates
Effective width	120mm
Feeding width	85mm
Forming steps	12 stations
Roller	Cr12 hard chrome plating within 0.05mm
Diameter of shaft	60mm
Main motor power	5.5 kw
Pump power	4 kw
Sprocket chain	1 inch
Drive type	by Gears
Cutting Blade	Cr12, heat treatment 60-62°C
Frequency Converter	It has the advantage of slowing down before cutting, to ensure the length accuracy (±1mm, far better than industrial standard ±3mm).
component	1 set of manual decoiler,1 set of main roll forming machine, 1 set of computer control cabinet, 1 set of hydraulic System,1 set of cutting mechanism, 1 set of counter,1 set of output table
Payment terms	cash,T/T,L/C.
Delivery time	30 working days

Blue Roller Shutter Door Roll Forming Machine Continuous PU Sandwich Panel Production Line

Product Tags:

roller shutter door making machine

garage door roll forming machine

Blue Roller Shutter Door Roll Forming Machine Continuous PU Sandwich Panel Production Line Images
